Introducing the Dix500, a unique limited-edition catamaran born of the DH550 and Dix470. Well known boat designer Dudley Dix has over the years successfully developed, tried and tested the radius chine plywood construction method, with great success. The Dix500 takes this method of construction to the next level in a professional build of 6 vessels only.
Composite Reinforced Wood Construction, draws on years of testing the combinations of sandwich core and cold mold. The goal is to develop a lighter yet stronger boat. This is achieved using “appropriate technology” at every level; from integral bulkheads of foam core with plywood and fiberglass skins bonded under vacuum and to interior cabinetry crafted from foam core panels. Individually crafted at our facility on the Albemarle Sound, this could be the boat of your dreams.
See the big brother boat at http://www.dixdesign.com/55cat.
Photo at left is Friends Forever a DH550 launched in 2016, sailing "the fairest Cape of them all" Vasco Dagama 1488
It all started with Wild Vanilla a 55' performance cruising catamaran, a unique design collaboration Dudley Dix and Phil Harvey, which Phil built in Trinidad
Wild Vanilla has been sold three times in the 15 years that she has been afloat, providing years of safe cruising to each of her owners
Interested in the progress of this build and the technical details that set this boat apart check out the Work In Progress Section
Check out past projects and boats that are especially suited to composite reinforced wood construction
1. Weigh in! yes displacement and heavy load makes all the difference to performance, and you can get a light performance blue water craft without the need to pay millions.
The DIX500 will launch at 24,000lbs and is available from 900,000.
Standard fiberglass production 50’ boat launches at about 48,000lbs and current cost above $1,200,000.
Carbon fiber production boat 50 feet floats at 18,000lbs and will cost a $2,000,000 and more.
2. The unique complete plywood double skin construction of the DIX500 with 38mm-52mm 1 ½” – 2” of foam sandwiched between it, will save on cooling or heating costs and make for an incredibly quiet ride and assure hours of peaceful sleep at anchor.
3. Worried about wooden boat water ingress or maintenance issues, the DIX500 exterior is 100% incapsulated in fiberglass laid with West System epoxy and finished in the best epoxy and polyurethane paint systems available.
4. The built-in redundancy resulting from the electrical and plumbing systems in each hull being set up as individual boats with connecting solenoid and electrical valves provides both the security of always having a fall back as well as the economy of being able to recharge on one engine.
Current Boat Under Construction $985,500.00 Planned launch November 2024
Vacuum pressed bulkheads start a strong accurate build
Internal paneling is vacuum pressed to ensure a light but strong product
A good vacuum system enables many special forms
Stringers set in bulkheads
The initial set up process ensures an accurate hulk
Radius ply section being formed.
Inner-skins fitted
Inner core finished for insulation and sound deadening
Fitting of outer skins
Fairing the keel position
Cruising keel fitted and glassed in place under vacuum
Final Glass done
Final fairing with AWLFair
Longboard work to achieve a fair hull
Bottom coat applied before roll
Port Hull Rolled !
First view of interior
Main cross member formed in Mahogany
Joining bulkheads under construction
Helm station made up in components
Front end formed on jig
Front end faired
Sugar scoop primed
The hulls finally mated
Aft view of main bulkheads forming the multihull
2023 Dix 500 by CRW-Con
Hull: Catamaran Round Bilge, cruising keel (dagger boards performance optional extra)
Designer: Dudley Dix Builder: CRW-Con
LOA: 15,2m/49’10” LWL: 14,3m/46’10” Beam: 7.70m/25’4”
Material: Composite: double skin on stringers with XPS core complete fiberglass exterior over integral bullheads vacuum formed with fiberglass and marine ply over Gurit structural foam. All exterior surfaces are covered in fiberglass.
Exterior Finishes: Below waterline Petit Protect + Vivid custom burnt orange. Hull sides Awlcraft custom burnt orange. Bridge deck Awlcraft white
Power: 2 x 57Hp Diesel Yanmar 4JH57 common rail series, 7° angle down gear, Gear box KM35A2, Shaft Q19 1.25” Propeller 3 blade standard (folding optional extra)
Mechanical: 1 x 24V Maxwell Anchor Windlass, 2 x 24V Harken Winch for sails, 1 x 24V Davit winch
Tanks: Fuel: 2 x 560lt/148gal aluminum 2 x 144lt/37gal day tanks integral composite
Water: 2 x 378lt/100gal
Holding: 2 x 106lt/45gal
Electrical: Alternators: 2 x 12V 125 Amp 2 x 24V 65 Amp
Shore power 1 x 50 Amp
House Battery Lithium 12V 2 x 300Ah 1 x 100Ah, 24V 2 x 150Ah
AGM 12v 1 x 115Ah isolated for critical circuits.
Inverter 2 x 4000W 40amp inverter chargers
Chargers 2 x Battery-to-battery 24V-24V 30Amp chargers
1 x 24VDC 30 Amp charger 1 x 12V 6Amp charger
1 x DC-DC charger 24V-12V
Diesel generator Next Generation UCM2-5.5. 120VAC 42 Amps 5000W
Electronics: Standard package for island hopping VHF, basic chart plotter, depth, and wind
Optional extras to suit the blue water sailor including, Radar, AIS, multi-function display auto pilot, and much more to keep you safe at sea.
Ventilation: 8 x hatches, 12 portholes,
Air Conditioning: 3 x 16,000BTU reverse cycle independent units
Heat: Hulls: blown air Salon: hydronic fan driven ( in floor optional extras)
Layout: 4 x twin berths, 2 x head (owner’s version available)
Plumbing: 2 x Head 24V fresh water electric flush
2 x ParMax 60PSI water pressure pumps
2 x Vetus calorifier 13gal/50L 120V 1Kw and twin coils from engine and diesel heater
All specifications subject to change prior to the signing of the build contract
The well placed helm; vital, functional and beautiful sets the tone for the interior of this boat
The steering wheel is well engineered using industry standard parts. The shaft is 1" diameter with 1"-13 thread. The wheel brake system is designed to use readily available Edson replacement parts
The pulleys for the steering system are manufactured in house to accommodate the Samson Amsteel Blue 5/16" ropes used for the steering system. Turnbuckles on the tiller arm allow fine turning to ensure the rudders constantly work in parallel.
The rudder system design deserves special mention; the shaft a thick-walled 4" 102mm 316 stainless steel tube rotates in Vesconite bearings housed in a fiberglass tube. The spade rudders are well balanced and the trailing edge is specially chisel shaped at 30 degrees to avoid chatter at higher speeds
The fuel fill and vent are connected to a Vetus no spill system. Also visible in this photo is the air inlet which supplies forced air to the bilge entering at the 3rd compartment of the hull and exciting aft through the engine compartment. This is connected to a timer which can be set for daily blow throughs at convenient times
Many of the sailboats designed in the early 1900's typically cedar plank on bent oak frames can be recreated, yes and again we reverse the old process. Laminated mahogany frames with a combination cold mold; cedar strip plank with diagonal mahogany veneers and fiberglass skin. Add hollow mast and spars constructed from Sitka Spruce and carbon fiber.
The result a very light super strong low maintenance craft.
Favorite designer BB Crowninshield and personal favorite Dark Harbor 17
